WDT large three-coordinate series numerically-controlled deep hole drilling machine WDT large three-coordinate series numerically-controlled deep hole drilling machine is used in drilling coordinate holes in large workpieces. Equipped with three-coordinate NC system, the column moves horizontally and the beam moves vertically, so to finish the machining of coordinated deep hole assembly. It is suitable for deep hole processing of large plastic molds, bars, heating plates, automobiles and machine parts and others, it can process 45# steel, die steel, alloy steel and other materials. The drilling depth ranges from 1000 to 3500mm. It can be designed according to user requirements.
主要技术参数	单位	WDT大三坐标系列 WDT large three-coordinate series
Main technical parameters	Unit	WDT1000-CNC	WDT1500-CNC	WDT2000-CNC	WDT2500-CNC	WDT3500-CNC
钻孔直径范围 Drilling diameter range	mm	4-25 / 4-38		6-25 / 6-38
钻孔深度 Maximum drilling depth	mm	1000	1500	2000	2500	3500
工作台尺寸 Worktable size	mm	1050×1500	2200×1600	3000×2000	3000×2000	5000×2000
工作台承重 Worktable load	kg	10000		30000
立柱横向移动范围 Horizontal movement range of column	mm	1500	2000	2000	2500
横梁垂向移动范围 Vertical movement range of beam	mm	600	1000	1000	1500
工作台至主轴中心高 Height from worktable to spindle center	mm	15-615	15-1015	15-1015	15-1515	15-1515
主轴个数 Spindle number	pcs	1
主轴转速 Maximum spindle resolution	r/min	5000		4000
主轴进给速度 Spindle feed rate	mm/min	10-350
快速移动速度 Fast moving speed	mm/min	X、Y=3000，Z=4000
冷却液压力 Maximum coolant pressure	MPa	10
冷却液流量 Maximum coolant flow	L/min	70		90
机床总功率约 Total power of machine tool (approx)	Kw	32 / 36		32 / 36
机床外形尺寸约 Machine tool dimensions (approx)	mm	5500×4500×2500	6100×5200×3000	7500×6000×3000	7500×6000×3700	10500×6000×3700
机床重量约 Machine tool weight (approx)	T	14	20	30	35	40
所有参数以合同为准 All parameters are subject to the specification in the contract,
